FREQUENCY AND DURATION OF OXIMETER DROP-OUTS IN THE NICU: AN OBSERVATIONAL STUDY

Summary

Oximeters used for continuous monitoring experience periods with no signal. This SpO₂ drop-out is widely acknowledged and its causes generally understood. This is a prospectively designed analysis of an existing database with the aim of characterizing drop-outs as experienced in the neonatal ICU. The data reflects 116 days of monitoring in seven tertiary care neonatal ICUs in 6 countries.  From the evaluation of 1,396 drop-outs we found that typically the time was minimal with missing SpO₂ data, and the episodes were short (median 2.79 minutes per day IQR 0.17–76, median 22 seconds IQR: 15–37, respectively). During about half of the days there were no prolonged dropouts (1 minute or longer), even so half of the total time spent with no SpO₂ data were in prolonged episodes (median length 110 seconds IQR 85–150). The predominate factor associated with excessive drop-out time was the number of prolonged episodes rather than their duration. We concluded that the impact of drop-outs during manual control of inspired oxygen primarily impact alarm fatigue, but that during automatic FiO₂ control they could have an important impact. The relative effectiveness of the fall-back strategies of these automatic control systems ought to be evaluated.

Keywords:

oximeter – oxygen saturation – neonatal ICU – SpO2 drop-out

Background

Continuous monitoring of neonatal oxygenation using the pulse oximeter is an essential tool in the neonatal intensive care unit (NICU). Relatively small changes in overall exposure to high and low extremes of peripheral oxygen saturation (SpO₂) levels have been shown to have significant impact on neonatal outcome [1, 2]. In addition, exposure to extreme levels have been shown to be primarily episodic with epi-sodes of 1 minute or longer contributing most signifi-cantly to bad outcomes [3].

While an essential tool, the use of the pulse oximeter is problematic. False alarms are common and known to create significant alarm fatigue [4]. It is well docu-mented that this leads to risks of frequent disregard for alarm policy and SpO₂ targeting guidelines [5].

The reasons for these false readings, that is artifact, are understood. They are primarily caused by motion, low regional perfusion and loss of sensor integrity. Even though the SpO₂ is calculated based on an average of 3–15 pulses, there are still occasions when no reading is presentable.  In this occasion it is said that
the SpO₂ reading “drops out”. While this is a common occurrence, we are unaware of any reports character-izing drop-outs in the NICU.

Much of the practice of adjusting the inspired oxygen using pulse oximetry is applied pragmatically by the attending nurse. General good practice would dictate that oxygen adjustments should be made judiciously, with a goal of avoiding responses to false positives or providing unnecessary extra oxygen in response to a short transient physiological perturbation. Periods of drop-outs are treated in the same manner. However, new neonatal ventilators offering nearly continuous automated adjustment of FiO₂ based on monitored SpO₂ have been shown to be quite effective [6]. International standards do require fail-back modes for periods of missing or unreliable signals. “Fall-back” being the preferred term to the commonly used, “fail-safe”.

As a part of our work to improve alarm and oxy-genation control practices, we are evaluating a large database of SpO₂ recordings from NICUs. As part of this EPI-SAT project, we supposed it important to characterize the frequency and duration of SpO₂ drop-outs as they occur in real NICUs.

Methods

The EPI-SAT database includes 116 days of continu-ous SpO₂ data from 58 significantly preterm infants receiving respiratory support and supplemental oxy-gen. These infants all participated in studies of SpO₂ control and are from seven neonatal ICU’s in six countries [7, 8]. Consent was received for participation in the studies and all the data in the EPI-SAT database is de-identified.

SpO₂ readings were collected every 5 seconds, by a data-logger attached to the digital output of a me-chanical ventilator (AVEA-CLiO2, Vyaire Medical, Irvine, CA, USA). The oximeter used Masimo SET technology (Masimo, Irvine, CA, USA) with averaging set at 8 seconds. Purpose built software (MatLab, MathWorks, MA, USA) evaluated drop-out episodes and parsed them into 5 duration categories: < 5 s, 5 to < 30 s, 30 to < 60 s, 60 to < 120 s, 120 to < 600 s. Episodes of 10 minutes or longer were excluded as likely procedural interventions, rather than drop-outs. The latter two categories (length of 1 minute or greater) were defined as being relevant to SpO₂ control (FiO₂ adjustment). High outliers were identified based on a standard nonparametric method. Specifically the high outlier threshold was the interquartile span plus the seventy-fifth percentile.

Differences between the outlier and non-outlier groups were compared with the Mann-Whitney U-test. Differences among the 5 episode length categories were compared with the Kruskal-Wallis test with Dunn’s procedure for pairwise comparisons. A two-tailed p < 0.05 was considered statistically significant. Statistical tests were conducted with XLSTAT v19.03 software (Addinsoft, Paris, France).

Results

We identified and analyzed 1,396 drop-outs during the 116 recorded days, that is 12 per day. The typical total time with missing SpO₂ readings (drop-outs) was minimal (median 2.79 minutes/day, range 0.17–76), obviously skewed. The actual median duration of indi-vidual drop-outs was 22 seconds (IQR: 15–37).

The distribution of drop-out time among the five duration categories was: 7% for < 5 s, 24% for 5 to < 30 s, 21% for 30 to < 60 s, 21% for 60 to < 120 s, and 29% for 120 s or greater. Thus about half of the drop-out time was deemed, according to our prospective definition, relevant to SpO₂ control. Details of the vari-ation among the duration categories are tabulated in Table 1. During 59 of the 116 days, there were no pro-longed drop-outs. When present, the median duration of these prolonged drop-outs was almost 2 minutes (110 s, IQR 85–150).

The differences in the frequency of and total length of time among each of the 5 categories are statistically significant (p < 0.001). The frequency of episodes between each categories were all statistically signifi-cantly different (p < 0.05), except between the two longest.  The time in the shortest category was not sig-nificantly different than in the two longest categories. Other differences were significant (p < 0.05).

Excessive drop-out time (outliers with >8.6 minutes of drop-out in a day) occurred in only 14 of the 116 days. In this group of outliers the median duration of time without SpO₂ readings was 16 minutes (IQR 11–31), significantly longer than the nominal group (2 minutes (IQR 1–4), p<0.001). The predominant factor in the difference between the two categories was the number of prolonged episodes, rather than their duration. The median duration of prolonged drop-out episodes in the outlier drop-out group was 134 s (IQR 8–147) and was not significantly different from nomi-nal group: 100 s (IQR 80–145). In contrast, the median rates of prolonged drop-outs per day were 4 (IQR 3.25–9.25) and 0 (IQR 0–1.0) respectively, and the difference was significant (p < 0.001). Other details of the difference in the frequency of prolonged drop-outs are tabulated by outlier category in Table 2.

The differences are statistically significant (p < 0.001).

Discussion

In this group of very preterm infants who required respiratory support and supplemental oxygen, oximeter dropouts were common, that is one every few hours. Furthermore, the total time without SpO₂ readings was relatively low and the typical duration of each episode relatively short. Only about half the days saw one or more prolonged drop-out, and only 12% of the days experienced an atypically high amount of time with drop-outs. We also found that in the case of the latter the total number of prolonged episodes was much higher.

The best practices for manual adjustment of inspired oxygen call for the nurse to observe the situation and only make adjustments after assessing the situation with the oximeter alarms and alerts as well as the infant. Response to a perturbation in SpO₂ quicker than 1–2 minutes, except in the case of an emergency, would be considered too fast. One study did look at the effect-tiveness of SpO₂ control with two manual strategies; attentive (45–75 s) and observative (130–195 s) [9]. They found that faster was better. Nevertheless, in routine care the risk of excessive overshoot in oxygen could only be mitigated with a dedicated operator as used in the study, so caution was advised. We found only a small percentage of the days of care were associated with frequent prolonged episodes, and most of those were shorter than 2 minutes. Thus, it would seem that the practice of only considering a change to FiO₂ if an alarm condition persists for 1–2 minutes mitigates most of the concern about what adjustment should be made during periods of drop out. Never-theless, false alarms from artifacts, including drop-outs, are a constant irritant and a source of the risk associated with alarm fatigue [10]. Further, one careful study did evaluate the likely SpO₂ reading following drop-out and Lim et al. concluded that blind adjustment to FiO₂ should not be made during drop-out [11].

Neonatal respiratory support systems that auto-matically adjust inspired oxygen based on SpO₂ (Auto-FiO₂) have become available from a number of compa-nies and are being widely adopted [12]. They continu-ously monitor SpO₂ and many make adjustments every second as necessary.

The long established international standard for phys-iological control systems require a fall-back function when the signal to the control algorithm is unavailable [13]. Because of the continuous SpO₂ signal into the controller, every drop-out no matter how short has impact and must be addressed. In general the approach of these Auto-FiO₂ controllers is not documented. One Auto-FiO₂ system stops the auto function when the input is unavailable, or if there is a major drop in SpO₂, and requires manual intervention by the clinician. Another system ignores short drop-out periods but if they persist changes the FiO₂ to a fall-back level based on several previous FiO₂ metrics. No fall-back ap-proach is perfect, but they all ought to be compared to standard manual care. One such study has just finished and the results are promising [personal communi-cation]. Predictably, it appears that following drop-outs Auto-FiO₂, when compared to manual control, reduces the likelihood of hypoxemia, and increases the likely-hood of normoxemia but also hyperoxemia. Auto-FiO₂ systems have been shown in clinical studies to be safe and effective [6]. However, suboptimal fall-back ap-proaches, as suggested by the work of Lim [11], might detract from their potential effectiveness, and potential-ly pose risks. These might include excessive overshoot from hypoxemia or swings between hypoxemia and hyperoxemia.

Our analysis has some limitations. First, each drop-out was treated as an independent event. It is likely that a period of several minutes of intermittent short drop-outs would have the same clinical impact on manual and auto control as one long episode. Although the total time with missing SpO₂ values was relatively small, the prevalence of clusters of drop-out ought to be explored. Second, while this is to our knowledge the first report of the characterization of drop-outs, it reflects the experience of 58 neonates, one study with a different oximeter suggests a higher frequency of drop-outs [11], which could reflect a different group of infants or a different averaging of the oximeter. Additional studies to broaden these findings and these results are warranted.

Conclusion

We confirmed that oximeter drop-outs probably do not generally impact clinical decision making during manual titration of inspired oxygen. While their prevalence is limited, and they are of short duration, they do contribute to false alarms and the potential for alarm fatigue as an acknowledged risk factor. In con-trast, we suggest their prevalence would have an impact on the effectiveness during automated control of in-spired oxygen. For this reason the fall-back approaches of commercially available systems ought to be docu-mented and evaluated.

Acknowledgement

The work was supported by a research grant SGS20/202/OHK4/3T/17 of the Czech Technical Uni-versity in Prague.

Author contributions

The first author (TB) provided the concept for the study, and wrote the first draft of the manuscript. The second author (KR) coded the data extraction software. Both authors critically reviewed the data and the manu-script.
